ALPHAGEO L2
Kategori: ALAT SURVEY KONSTRUKSI & PEMETAAN,GNSS RTK | Dilihat: 579 Kali
Brand:
Rp 25.000.000
Kode Produk: L2
Stok: Stok Tersedia
Berat: -
Sejak: 13-06-2025
Detail Produk
Specifications
| GNSS Performance | Channels | 1408 |
| Data Format | RTCM2.X、RTCM3.X | |
| Signals tracking | GPS: L1C/A,L2C,L2P, L5 | |
| GLONASS: L1,L2 | ||
| BDS: B1,B1C, B2, B2a, B2b, B3 | ||
| GALILEO: E1, E5a, E5b, E6 | ||
| QZSS: L1, L2, L5, L6 | ||
| SBAS: WAAS, EGNOS, MSAS, GAGAN, SDCM | ||
| Cold start | <60s | |
| Hot start | <15s | |
| Positioning output rate | 1Hz~50HZ | |
| Signal reacquisition | <1s | |
| RTK initialization time | <5s | |
| Initialization reliability | >99.99% | |
| Time accuracy | 20ns | |
| Positioning accuracy* | Static GNSS surveying | H:±(2.5mm+0.5ppm) |
| V:±(5mm+0.5ppm) | ||
| RTK surveying | H:±(8mm+ 1ppm) | |
| V:±(15mm+1ppm) | ||
| Laser surveying | ±1cmm+5mm/m | |
| IMU | Sensor | Supported,4D lMU |
| initialization in 3 seconds | ||
| Update rate | 400Hz | |
| Accuracy | <2.5cm within 120° | |
| Tilt compensation | 0~120% | |
| Communications | l/O interface | Type-C |
| Bluetooth | Bluetooth V4.0 | |
| Electrical | Battery | Built-in Li-ion battery,supports external power supply |
| Capacity | 2000mAh | |
| Battery life | >12hrs | |
| Interface | Type-C 5V/2A | |
| Environmental | Operating temperature | -20°C~+75°C |
| Storage temperature | -40°C~+85°C | |
| Protection IP | IP67 | |
| Shockproof | Survive a 2m pole drop onto concrete | |
| Vibration | MIL-STD-810G | |
| Humidity | 100%Non-condensing | |
| Physical | Dimensions | 120mmx61mmx41mm |
| Weight | 170g | |
| Materials | Polymer engineering materials | |
| Keys | Power button | |
| Indicators | 1*Satellite indicator | |
| 1*Bluetooth indicator | ||
| 1*Data communication | ||
| 1*Power indicator |
