• Precise green laser and built-in camera allow precise measurement of distant or hard-to-reach points
• Supports tracking 1668 channels for all running and existing constellations
• Dual-camera technology enhances visual stakeout with real-time 3D guidance for efficient operations
• Auto-IMU enables 120° tilt compensation in conventional, laser, and visual modes without manual initialization
• Super datalink supports multiple protocols and achieves a 15km range with SNLonglink under ideal conditions
• An OLED color screen shows satellite status, power, and more for easy field monitoring

Performance

• Channel
  1668
• Satellites tracking
  GPS: L1C/A, L1C, L2P, L2C, L5
  BDS: B1l, B2l, B3l, B1C, B2a, B2b
  GLONASS: L1, L2, L3
  Galileo: E1, E5a, E5b, E6c, E5 AItBOC
  QZSS: L1C/A, L2C, L5, L1C
  IRNSS: L5
  SBAS: L1C/A
  PPP: B2b & HAS
  L-Band
• Signal Re-acquisition
  ≤1s
• Cold Start
  ≤30s
• Hot start
  ≤10s
• RTK Initialization Time
  <5s(Baseline≤10km)
• Initialization Reliability
  ≥99.9%
• Data Update Rate
  1Hz, 2Hz, 5Hz, 10Hz, 20Hz
• Static and Fast Static
  Horizontal 2.5 mm + 0.5 ppm RMS
  Vertical 5 mm + 0.5 ppm RMS
• Long Observations Static
  Horizontal 3.0 mm + 0.1 ppm RMS
  Vertical 3.5 mm + 0.4 ppm RMS
• Single Baseline RTK
  Horizontal 8mm + 1ppm RMS
  Vertical 15mm + 1ppm RMS
• DGPS
  ＜0.4m RMS
• SBAS
  Horizontal 0.5m RMS
  Vertical 0.8m RMS
• Standalone
  1.5m 3D RMS
• Laser Tilt Measurement
  ≤3.5cm (5m range, ≤60°Tilt in laser mode)

Laser Specification

• Range
  50m
• Laser Safety
  Class 3R
• Accuracy (room temperature)
  (3-5)mm + 1ppm
• Measuring Frequency
  Classic Value: 3Hz
  Maximum Value: 5Hz
• Laser Injection Power
  0.9mW~1.5mW
• Working Temperature
  -20°C~+50°C
• Storage Temperature
  -30°C~+60°C
